ISO9001 Aluminum Sheet Metal Enclosure Fabrication Video Camera Housing

Aluminum Video Camera Housing of High Speed Train Sheet Metal Enclosure Fabrication

Compound Blanking Operation

1. Material Selection: Select a sheet metal material suitable for the complexity of the compound blanking process, considering factors like material thickness and formability.
2. Blank Design: Develop a blank design that incorporates multiple features, including holes, notches, and intricate shapes, that can be achieved through compound blanking.
3. Die Construction: Construct a compound blanking die, which comprises multiple cutting and forming elements to achieve the desired blank shape and features.
4. Blanking and Forming: Feed the sheet metal into the compound blanking press, where the blank is cut and simultaneously undergoes various forming operations to produce the final component.
5. Quality Assurance: Perform a thorough quality inspection to ensure that the compound-blanked components meet the precise dimensional and feature requirements.
